An easy way to add machine vision to your robot. Camera setup in less than 30 minutes. It incorporates all the softwares to load the camera options in the robot. You will no longer need items to come in an orderly fashion to grab them.

Characteristics

Easy to use

•  Plug + Play
•  UR + certified products
•  Free programming software

Control on the programming console:

•  2 instruction methods for custom objects
•  No external PC required
•  Powerful color validation

For industrial needs:

•  Sealed and compact hardware
•  Slim design that fits all UR joints
•  Adjustable focus and lighting

Custom detection settings

•  Adjust focus and built-in light to optimize programming and running conditions

Color validation

•  Improve model detection and enable object classification during manipulation
• specs
• Focus radius: 70mm to infinity
• Integrated lighting: Two units (white and diffuse LED)
• Programmable parameters:
  -Automatic and parametric programming of parts
  -Editing edges, color validation
  -Focusing, lighting on / off
• Electric: Direct communication with the UR controller (via USB), and power supply from the controller (24V)
• Mass: 160 g
• Operating temperature: 0ºC to 50ºC
